CNC working centres with 5 interpolated axis

• Place of Origin:

   Italy

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1461658

• Place of Origin:

  Italy
• It''''s Breton''''s ContourFive NC 700, that was specially developed to machine workpieces featuring a complex 3D shape.
  ContourFive 700 is a CNC shaping, contouring, cutting and turning centre with five inter-polated axes and a fixed worktable, that offers the users the possibility of performing mul-tiple and complex machining operations which would otherwise require several machines:
  - sawing of slabs and small blocks into workpieces utilising the xxxxxxsaw bladexxxxxx
  - shaping of either large or small blocks utilising the xxxxxxsaw bladexxxxxx to get large pieces with complex shape, such as capitals, banisters, tanks, fireplace components, etc.
  - shaping and dishing out utilising millers to get shower trays, sinks, vases, bas-reliefs, engravings, etc.
  - contouring utilising shaped tools to produce statues, kitchen tops, tombstones, components for funerary art, etc.
  - turning of columns with shaped profiles or machining of columns to create a twisted ef-fect all along the surface
  CNC centre with 5 axis shaping contouring sawing turning marble granite stone slab block
  ContourFive NC 700 stands out thanks to its performances:
  - mobile bridge structure enabling an excellent access to the worktop
  - short beam ensuring top rigidity
  - "rapid" movements of up to 40 metres/minute
  - high-frequency spindle with 20 kW and 14.500 rpm, which can be turned in the space along the 5 axes and controls automatically a xxxxxxsaw bladexxxxxx w- max. diameter of the xxxxxxsaw bladexxxxxx: 400 mm
  - "C" axis rotation: ± 200°
  - "A" axis rotation: from 0° to +115°
  - "X" axis travel: 3.700 mm
  - "Y" axis travel: 2.800 mm
  - "Z" axis travel: 700 mm
  - possibility of working with xxxxxxsaw bladexxxxxxs, shaped tools, drills, millers, etc.
  - mobile carrousel-type tool-store with 27 cells + 1 (optional) cell for the xxxxxxsaw bladexxxxxx
  - lathe (optional) for machining both columns and capitals
